Technical Data:
|
Model
|
SHAB-80C
|
|
Output force
|
31T
|
|
Rated pressure
|
700bar
|
|
Throat depth
|
80mm
|
|
Max steel thickness
|
13mm
|
|
Dimensions
|
90×210×360mm
|
|
Throat Depth
|
80mm
|
|
Dies
|
ø10.5, 13.5, 17.5,20.5mm
|
|
Weight
|
13.5kg
|
|
Standard accessaries
|
1 fixed spanner
|
|
1 hex spanner
|
|
|
Packing
|
Steel case or compact plastic case
|
Features:
1. For punching angle steel in L shape, I-beam in H shape ,flat steel plate,copper and aluminium busbars
2. Quick punching with smooth punching surface without burr ; positioning plate design for precise location without offset
3. Hydraulic puncher make punching safe and clean without punching chipping
4. Available in job site use or fixed in a shop for batch cut work .
5. Equipped with quick coupler for easy disassembly
1. For punching angle steel in L shape, I-beam in H shape ,flat steel plate,copper and aluminium busbars
2. Quick punching with smooth punching surface without burr ; positioning plate design for precise location without offset
3. Hydraulic puncher make punching safe and clean without punching chipping
4. Available in job site use or fixed in a shop for batch cut work .
5. Equipped with quick coupler for easy disassembly
