Technical Data:
|
Output Pressure
|
700bar / 70Mpa
|
|
Oil Delivery at Low Pressure
|
7.5L/min
|
|
Oil Delivery at High Pressure
|
1.2L/min
|
|
Tank Capacity
|
10L
|
|
Rated Engine Speed
|
3600 rpm
|
|
Dimension
|
650×370×500mm
|
|
Net Weight (Hydraulic Oil Included)
|
53kgs
|
Features:
1. Large oil capacity, suitable for large capacity crimping tools and long time
operation without engine overheating
2. High and low double-speed automatic switch, well fit for 60T 100T 200T 300T
crimping tools
3. Rated output pressure 70Mpa, maximum up to 90Mpa
4. Retract pressure protection system &overflow protection valve,safe and reliable
5. Simple structure, easy operation, light weight
6.Low noise, environment friendly
7. Equipped with pressure gauge for easy output confirmation
1. Large oil capacity, suitable for large capacity crimping tools and long time
operation without engine overheating
2. High and low double-speed automatic switch, well fit for 60T 100T 200T 300T
crimping tools
3. Rated output pressure 70Mpa, maximum up to 90Mpa
4. Retract pressure protection system &overflow protection valve,safe and reliable
5. Simple structure, easy operation, light weight
6.Low noise, environment friendly
7. Equipped with pressure gauge for easy output confirmation
